400G Coherent TMUX:1CFP+4QSFP28

Part of the DWDM/CWDM/OTN transmission

The 400G coherent TMUX service card supports four 100GE service accesses, adopts advanced technologies such as 16QAM modulation and coherent reception, and overcomes the transmission physical effects of high-speed transmission systems on OSNR requirements, CD tolerance, PMD tolerance, and non-linearity.

It can realize 400GE business over 400 kilometers of non-relay transmission, and the line side interface supports C-band 96-wave (50GHz) tunable.

Get A Quote Now

Typical Applications Technical Specifications Related Euipment Related Download

容器 29@1x.webp

Technical specifications

Function	Description
Interface	• Client-side interfaces: 4, pluggable based on QSFP28 • Line side interface: 1, based on 400G CFP2 pluggable, coherent 16QAM
Line mode	Support transparent transmission of 1*400GE service, which can convert 4 channels of 100GE service optical signals on the client side into 1 channel of 400G rate DWDM standard wavelength optical signals
Repeater mode	Support 400G wavelength electrical relay
Support business type	• 100GE
WDM technology	Support DWDM: C-band 50GHz 96 waves tunable
FEC technology	Support oFEC
Number of occupied slots	Support OSP3800 full series chassis, occupying 2 slots, (1RU)
Network management function	• Support real-time monitoring of port working status, including: transmit optical power, receive optical power, temperature, error code statistics etc. • Support port loop-back function and port shutdown function
Max power consumption	65W (including optical module)
MTBF	＞100,000 hours
