Home >   Products >   OLM Optical Line Monitoring System
容器 30@2x.webp
容器 30@2x.webp

OLM Optical Line Monitoring System

Part of the DCI-BOX transmission

Optical cable monitoring system combines optical cable monitoring, alarm, fault analysis, positioning, fault management, line maintenance and line management to ensure the safe and efficient operation of the optical cable network. It can automatically monitor the communication optical cable 24 hours a day and automatically switch and protect the optical fiber.

It can timely and accurately report the sudden optical cable fault, effectively shorten the fault duration, and It is necessary to find the potential faults that are hidden and not yet detected, but will cause communication interruption, and give accurate early warning, so as to achieve active maintenance and take preventive measures.

Get A Quote Now
Schematic Diagram Product Features Technical Specifications Related Euipment Related Download
容器 29@1x.webp

Product Features

• High-integration

Business card precision design, small size, high density.

• Strong versatility

It supports dozens of cards and is compatible with OTN and OLM.

· Diversified product forms

It can provide different product forms of 1RU, 2RU,3RU, 5RU, suitable for different application combinations.

• Flexible upgrading and expansion

It adopts plug and play design, easy to use, easy to upgrade, and short cycle of new function card.

Technical specifications

FunctionDescription
Equipment Size(W × D× H, mm)Support 1U/2U/3U/5U design
Max channel number CWDM

18 wavelength, DWDM: 96 wavelength(50GHz）

Card
OTDR Card/OSW Card/OPM(OPD、OPC)Card/OS Card/WDM Card/OLP Card
Clock featuresSupport IEEE 1588V2
Network topology

Point to point, chain type, star type, ring type

Network level protectionOptical channel 1+1 protection, optical multiplex 1+1 protection, optical line 1+1 protection
Equipment level protection Power supply backup
Network management

SNMP, Web, CLI, Telne

Installation

19"and 23" cabinets, ETSI 600mm cabinets Wireless outdoor base station cabinet, FTTX outdoor cabinet, hanging wall

Working temperature range

-10℃～60℃

Working humidity range5~95% no condensation
Storage temperature range-40℃～85℃
Heat dissipation

Fan cooling

Power supply mode AC: 90 ~ 260 V or HDC:127~370 V or DC:-72 ~ -36 V
