Home >   Products >   40G&100G OEO: 6*QSFP28
IMG_3159 拷贝(1).webp
IMG_3159 拷贝(1).webp

40G&100G OEO: 6*QSFP28

Part of the DWDM/CWDM/OTN transmission

The 40G&100G incoherent OEO service card supports three 40GE or 100GE bilingual service access. Its main function is to perform 3R regeneration of three 40GE or 100GE service signals that are accessed, and can be transformed into three WDM standard wavelength optical signal, so that the multiplexer unit performs wavelength division multiplexing on optical signals of different wavelengths, and at the same time implements the inverse process of the above process.

It’s suitable for short-range transmission of wavelength division in metro areas at 40G or 100G rates.

Get A Quote Now
Typical Applications Technical Specifications Related Euipment Related Download
容器 28@1x.webp

Technical specifications

FunctionDescription
Application100G wavelengths transform40G wavelengths transform
interface

• Client-side interface: 3 QSFP28 hot-plugging

• WDM-side interface: 3 QSFP28 hot-plugging

• Client-side interface: 3 QSFP+ hot-plugging

• WDM-side interface: 3 QSFP+ hot-plugging

Line mode

Supports three 100G service transparent transmissions,

which can transform three 100G service optical signals

into two WDM standard wavelength optical signals.

Supports three 40G services for transparent transmission,

which can transform three 40G service optical signals

into two WDM standard wavelength optical signals.

Support service type

• 100GE

• OTU4

• 40GE

• OTU3

Relay mode

• Support 40G&100G wavelength electrical relay

• Optical signal single, multi-mode transform

WDM technologySupport DWDM: C band 100GHz 40/48 waves,50GHZ 80/96 waves
Occupied slot numberSupport OSP3800 series chassis, occupy 1 slot , (0.5RU)
Network management function

• Support real time monitoring of the port working state, including:

transmitting optical power and receiving optical power, temperature, etc.

• Support port loop-back and port shutdown

Max power consumption30W (including Module)
MTBF＞100000 hours
