EDFA: Erbium-Doped Fiber Amplification Card

Part of the DWDM/CWDM/OTN transmission

EDFA is an erbium-doped fiber amplification card.Its main function is to compensate the power of the signal light in the transmission link, and it can amplify the optical signals of up to 48 channels (channel interval of 100 GHZ) or 96 channels (channel interval of 50 GHZ) at C band at the same time.

It has the characters of flat gain, locked gain, low noise figure, etc. and it’s an indispensably important component for DWDM system, future high speed system and all-optical network long-distance transmission.

Get A Quote Now

Typical Applications Technical Specifications Related Euipment Related Download

容器 29@1x.webp

Technical specifications

Function	Description
working wavelength range	Standard type: 1529nm~1561nm Applicable to 40 wavelength(100GHz) or 80 wavelength(50GHz)DWDM system
working wavelength range	Extension type: 1528nm~1568nm Applicable to 48 wavelength(100GHz) or 96 wavelength(50GHz)DWDM system
EDFA TYPE	OBA	OLA	OPA	R/B-EDFA
Min input optical power	-22dBm	-30dBm	-32dBm	-30dBm
Max output power	+20dBm	+20dBm	+16dBm	+20dBm
Max Gain	12dB	25dB	25dB	25dB
Noise factor	＜5.5dB
Gain flatness	＜1.5dB
Secondary amplification	Support built-in dual pump (optional) for signal secondary amplification
Unique technology	Support gain locking technology, transient control technology automatic shut-off technology of output optical power
Network management function	• Support real time monitoring for EDFA port working state, including: optical power, optical pumping, temperature, etc. • Support pump shutdown threshold and automatic recovery time setting function
Occupied slot number	Support OSP3800 series chassis, occupy 1 slot, (0.5RU)
Optical interface	LC/UPC
Max power consumption	30W
MTBF	＞100000 hours
