10G TMUX: 8*1.25G↔10G

Part of the DWDM/CWDM/OTN transmission

The 10G incoherent muxponder service card supports supports 8*100mbps port converging one 10G port or 8*1.25gbps port converging one 10g port, and can convert the multiplexed/demultiplexed optical signals into WDM standard wavelength optical signals, so as to facilitate the wavelength division multiplexing of optical signals of different wavelengths by the combining unit, and realize the reverse process of the above process.

It is suitable for 10G forward multiplexing in metropolitan area.

Get A Quote Now

Typical Applications Technical Specifications Related Euipment Related Download

容器 29@1x.webp

Technical specifications

Function	Description
Application	8x1.25G↔10G & 8x100M↔1.25G
Interface	• Client-side interface: 2 QSFP28 ,hot-plugging • WDM-side interface: 1 100G/200G CFP2 ,hot-plugging, coherent QPSK
Basic function	Supports 8100Mbps service optical signals to be multiplexed into one 10G rate WDM standard wavelength optical signal Supports 81.25G service optical signals to be multiplexed into one 10G rate WDM standard wavelength optical signal
Support service type	• Supports 8-channel FE/GE transparent service transmission
WDM technology	Support DWDM: C band 100GHz 40/48 waves
Occupied slot number	Support OSP3800 series chassis, occupy 1 slot, (0.5RU)
Network management function	• Support real time monitoring of the port working state, including: transmitting optical power and receiving optical power, temperature, etc. • Support port loop-back and port shutdown
Power consumption	20W (max, including Module)
MTBF	＞100,000 hours
